Blue Sea Battery Switch Four Position with AFD E-Series

Product Information

Specification

Blue Sea Battery Switch Four Position with AFD E-Series

Also Known As:

Four Position, Battery Switch, E-Series, Blue Sea, Durable Aluminum Case, Alternator Field Disconnect

About:

Blues Sea Systems compact high-amperage switches are vapor/ignition protected and UL listed. These switches are built with safety in mind. They are designed to isolate the battery to prevent the spread of flame if a fire breaks out onboard a marine vessel. In fact, the ABYC requires a switch like this on all boats that have more than 800 cranking amps.  They are simple is install and built with longevity in mind. This is why you will find them on some of the biggest boats out there. The E-Series are 350 Amp continuous rated for outboards, small gasoline or diesel engines. 350 Amps continuous, 600 Amps (5 mins.) intermittent rating. Crank rating (10 sec.) 2000 Amps (1 min.) 1000 Amps.

Construction:

• Mounting holes: 1/4" (M6) Screw
• Studs accept 3/8" (M10) ring terminals
• 7/8" (22 mm) Stud length accepts multiple cable terminals
• Tin-plated copper studs for maximun conductivity and corrosion resistance

Strands:

• CE
• IP 66
• UL 1500
• ISO 8846
• SAE J1171

Features:

• Advanced Multi Stage Charging
• Built In Safety Features
• Durable Aluminum Case
• Tactile indicator knob position by feel
• Fits most Perko and Guest low amperage battery switch hole patterns
• One-piece terminal stud design never loosen over time
• Case design allows surface, rear, or front panel mounting options
• Selector type battery switches with a "make or break" contact design allows switching without power interruption

Specifications:

• Switch Positions : 4
• Color : Red
• Maximum Voltage : 32 V DC
• Continuous Rating : 350 A
• Intermittent Rating : 600 A (5 min)
• Battery Inputs : 2
• Dimensions : W=2.82", H=2.82", D=3.07"
• Part Number: EBS-9002E
