Product Information

Specification

Also Known As :

2-hole ProtoBoard pattern,Anti-tarnish coating,Lead free and RoHS compatible

About :

ProtoBoards are widely used by electronics hobbyists, students, and engineers during the initial stages of circuit design and testing. They provide a convenient and flexible platform for trying out different circuit configurations before committing to a final design on a custom PCB.

Common Applications: :

                     In electronics, "hole strips" can refer to rows or columns of holes on a prototyping board (such as a breadboard or perfboard) that are used for inserting and connecting electronic components and wires. These hole strips are designed to facilitate the construction and testing of electronic circuits without the need for soldering.

Standards:

◐ Grid of Holes: ProtoBoards typically consist of a grid of holes or pads arranged in rows and columns.
◐ No Soldering Required: Unlike traditional PCBs where components are soldered in place, ProtoBoards are designed for solderless prototyping.
◐ Component Placement: ProtoBoards often have labeled rows and columns to help users identify and organize the placement of components.

Construction :

Attachment Points: Mounting holes provide secure attachment points for fasteners like screws, bolts, nuts, washers, or rivets.
Alignment: Mounting holes are often used for aligning and positioning objects or components accurately.
Strength and Stability: Mounting holes can enhance the strength and stability of structures or assemblies.
Modularity: In modular design and construction, mounting holes allow components or modules to be easily attached or detached, facilitating the assembly, maintenance, or replacement of parts.

Part Number	PR2H1
Size 1	50 x 80mm (1.97 x 3.15in),
Holes	(2.54mm) centers.
Thick	1/16" thick (1.6mm)

Features :

◐ Convenient 2-hole ProtoBoard pattern provides an easy way to connect parts.
◐  1oz/ft2 copper with an anti-tarnish coating for easy soldering. Lead free and RoHS compatible.
◐ 31 x 19 holes, 0.037" holes are drilled on 0.1" (2.54mm) centers. Four 0.125” mounting holes.
◐ Size1 = 50 x 80mm (1.97 x 3.15in), 1/16" thick (1.6mm)
◐  ProtoBoard saves time! ProtoBoard-2H has a general purpose stripboard circuit pattern that is pre-cut with 2 holes per segment.
◐ 0.1" hole spacing for DIP integrated circuits and headers.
◐  BusBoard Size1 is ¼ the size of a standard 3U size VME board.
◐ Four mounting holes provided
