Indoor/Outdoor Breakout B-Series 2.0mm 12 Strand Tight Buffered Multimode Black Jacket Riser Cable BE012DALT9KR
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Tensile Load | Menimum Bend Radius | |||||||
| Diameter | Weight | Installation | Operational | Installation | Long Term | |||
| Fiber Count | Fiber Type | Part Number | mm/(in) | kg/km (lbs/1,000) | N (lbs) | N (lbs) | cm (in) | cm (in) |
| 12 | ALT - 50µm OM3 | BE012DALT9KR | 10.9 (0.43) |
108.0 (76.65) |
4,800 (1,000) |
1,200 (270) |
16.4 (6.5) |
10.9 (4.3) |
APPLICATIONS:
• Ideal for installations requiring an extremely rugged and reliable cable design where maximum mechanical and environmental protection are necessary
• Typical industrial uses are factory automation, power generation and other utilities, oil and gas refining, and surface mining
• Easiest cable to install where direct termination of the subcable to a connector and a direct run to panels and equipment are desired
• Ideal for locations requiring low-temperature performance along with a flame rating
STANDARDS:
OCC Indoor/Outdoor tight-buffered fiber optic cables meet the functional requirements of the following standards:
• UL 1666
• CSA C22.2 No. 232
• CSA C22.2 No. 230
• GR-409-CORE
• ICEA-S-104-696
• ICEA-S-83-596
• TIA-568
• TIA-598
CHARACTERISTICS:
| Characteristics | PVC Outer Jacket |
| Operating Temp | -40°C to +85°C |
| Storage Temp | -55°C to +85°C |
| Install Temp | -10°C to +60°C |
| Flame Retardancy | UL listed type OFNR (UL 1666) and FT4 (CSA C22.2 No. 232) |
| Crush Resist | 2200 N/cm |
| Impact Resist | 1500 impacts |
| Flex Resist | 2000 cycles |
| Jacket Type | D |
FEATURES:
• Fiber Optic tray Cable: Suitable for use in cable trays
• Individual fibers and strength members protected in a subcable configuration
• Most rugged cable design with individual subcables for routing to diverse intelligent devices with direct connector termination at each device
• Meets all applicable standards for Impact & Crush Resistance (CSA C22.2 No. 230)
• Fibers may be directly terminated at factory devices or central locations using connectors with no further protection required
• J-Jacket is UV, fungus and moisture resistant
• Designed for indoor/outdoor installations, including cable trays
• 2 to 72 fiber counts are available with 2.0mm or 2.5mm subcables
• Low-temperature PVC outer jacket (J-Jacket) provides excellent performance and flexibility at low temperatures
• Wide operating temperature range of -50°C to +75°C
• Core-locked™ jacket prevents cable from flattening and the jacket from wrinkling in tight bends:
• Permits pulling with direct attachment of wire mesh grip; not need to access inner aramid strength members
• Improved crush and tear resistance
• Contains 25% more material than conventional jackets
• High crush and tensile load ratings compared to similar tray service fiber optic cables
• Oil resistant for use in industrial applications (J-Jacket)
• UL listed in accordance with NEC section 770.179(b) for use in vertical runs in building riser shafts or from floor to floor
• Designed to exceed the flammability requirements of Chapter 8 of IEEE 383
