About :
The S100X650VAM Die-Cut Self-Laminating Label Cassette includes both label material and ribbon for easy changeover. Self-laminating adhesive labels for wire/cable identification include a white print-on area and a clear overlaminate. For use with the MP300 printer. Vinyl. 1" x 6.5" (25.4 mm x 165.1 mm). Wire/Cable Size Range 1/0-250 MCM. Color Clear/White.
Specification :
| Note | For use with MP300 printer |
| Product Type | Self-Laminating Label |
| Sub Brand | PXE™ |
| Color | White |
| Compatible Wire Gauge (AWG) | 1/0-250 MCM |
| Material | Vinyl |
| Number of Labels per Cassette | 45 |
| Standards Met | RoHS Compliant |
| Minimum Cable Diameter (In.) | 0.48 |
| Minimum Cable Diameter (mm) | 12.2 |
| Maximum Cable Diameter (In.) | 1.59 |
| Maximum Cable Diameter (mm) | 40.4 |
| Label Height (In.) | 6.5 |
| Label Height (mm) | 165.1 |
| Label Width (In.) | 1 |
| Label Width (mm) | 25.4 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Maximum Operating Temperature (°C) | 66 |
| Maximum Operating Temperature (°F) | 150 |
| Print-On Area Height (In.) | 1.5 |
| Print-On Area Height (mm) | 38.1 |
| Label Application | Cable & Wire Marking |
| Overall Width (In.) | 1 |
| Overall Width (mm) | 25.4 |
