6 AWG Compression Splice Pan-Lug Standard Copper Blue SCSF6-L (Pack Of 50)
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
About ;
Introducing the 6 AWG Compression Splice Pan-Lug Standard Copper Blue SCSF6-L, the ultimate solution for seamless electrical connections. Crafted with precision and engineered for reliability, this compression splice pan-lug is designed to meet the highest industry standards, ensuring superior performance in demanding electrical applications.
Specification :
| Product Type | Compression Splice |
| Sub Brand | Pan-Lug |
| Copper Conductor Size (AWG) | 26.25 |
| Copper Conductor Size (kcmil) | 26.25 |
| DLO Copper Flex Conductor Size (AWG) | 6 |
| Class K Copper Flex Conductor Size (AWG) | 6 |
| Class M Copper Flex Conductor Size (AWG) | 6 |
| Barrel Type | Flared |
| Maximum Voltage (kV) | 35 |
| Base Material | Copper |
| Finish/Coating | Tin-Plated |
| Color Code | Blue |
| Panduit Die Index Number | P24 |
| Overall Length (In.) | 1.75 |
| Overall Length (mm) | 44.5 |
| Wire Strip Length (mm) | 20.6 |
| UL Temperature Rating (°C) | 90 |
Download PDF Spec Sheet
