4K 32CH PENTA-BRID HDCVI DVR 8TB Dahua Tech X88B5S8
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Operating System | Embedded LINUX |
| Main Processor | Embedded Processor |
| Performance | • Human and Vehicle object classification • Decreased false alarms from leaves, lights, animals • Configure function on 6 channels • 10 Tripwire/Intrusion rules per channel |
| Object Classification | • Human or Vehicle • Secondary Recognition for Tripwire and Intrusion |
| Analog Camera Input | 32 Channels, BNC |
| HDCVI | 8 MP, 6 MP, 5 MP, 4 MP, 1080p 720p |
| IP Camera Input | 32 Channels, each channel up to 12 MP (The recording rate is dependent on the maximum resolution and frame rate of the connected IP camera.) |
| Two-way Talk | Input: One (1) Microphone, BNC Output: One (1) Channel, BNC |
| Audio | Input: 16 Channels, BNC Output: One (1) Channel, BNC |
| Part No | X88B5S8 |
4K 32CH PENTA-BRID HDCVI DVR 8TB Dahua Tech X88B5S8
DESCRIPTION :
The X88B Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X88B takes advantage of HDCVI technology for easy integration into existing video surveillance systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously, plus the DVR delivers 4K resolution on each HDCVI or IP channel.
FEATURES :
⦿ 4K at 7 fps Recording Resolution on All HDCVI Channels
⦿ Dual-stream Video Recording
⦿ Smart H.265+ and Smart H.264+ Dual Codecs
⦿ Auto-detection and Auto-configuration of Video Inputs
⦿ 32 IP Camera Channels, each channel up to 12 MP
⦿ Maximum 128 Mbps Incoming Bandwidth
⦿ Analytics+ Functions: Perimeter Protection and Smart Motion Detection
⦿ Spot Output (HDMI 2 Output)
⦿ Five-year Warranty (for products sold through an authorized Dahua dealer)
Download PDF Spec Sheet
