Indoor/Outdoor Distribution Series Ultra Fox 12 Fiber ILA with Low Smoke PVC Single Mode 900µm Tight Buffer Yellow Plenum Cable DZ012TSLX9YPI8

Product Information

Specification

DESCRIPTION:

Offering the durability you expect from OCC, these distribution cables provide all of the indispensable elements needed for Indoor and Indoor/Outdoor commercial applications, while providing great value. Manufactured with Indoor/Outdoor grade low smoke PVC for plenum applications.

Interlocking aluminum armor may eliminate the need for conduit, reducing installation costs for commercial or other installations requiring a metallic conduit.

APPLICATIONS:

• Used in trunking, LAN and distribution applications where small size, lightweight, and versatile installation capability are required for ducts, plenums, and air handling spaces
• Ideal configuration for a single termination point requiring multiple fibers
• Aluminum interlocking armor with Low-Smoke PVC over-jacket
• Interlocking armor can be easily removed leaving an intact plenum rated inner cable
• Ideal for locations that require conduit for cable protection
• Indoor/Outdoor plenum cables eliminate the need for costly cable transitions in different installation environments

CHARACTERISTICS:

FEATURES:

• UL Listed in accordance with NEC section 770.179(a) for use in ducts, plenums and air-handling spaces
• Low-smoke PVC inner and outer jackets
• 2- to 24- fibers
• Cable materials are Indoor/Outdoor UL-Listed OFCP and also UV, water and fungus resistant
• High performance tight-buffered coating on each fiber for environmental and mechanical protection
• 900 µm buffer works well with both Xpress Ultra mechanical connectors and fusion splice pigtails
• Can be installed outside and in plenum or riser pathways inside, eliminating the need to transition cable types between environments
