8 Ohm 10" Bass Midrange for PA Applications upto 4200 Hz 300 W PAW 25 3050

Name: 8 Ohm 10" Bass Midrange for PA Applications upto 4200 Hz 300 W PAW 25 3050
Brand: Visaton
SKU: 3050
Availability: InStock
Rating: 4.91 (8347 reviews)

Roll over image to Zoom

8 Ohm 10" Bass Midrange for PA Applications upto 4200 Hz 300 W PAW 25 3050

Write a Review

Ask a Question Download PDF Buyer Guide

SKU: 3050

Select a Variant

8 Ohm 10" Bass Midrange for PA Applications upto 4200 Hz 300 W PAW 25 3050

Price:

Shipping Cost Calculated at Checkout. Standard Lead Time is 1 to 6 Business Days.

Qty:

Where are we? 4 Continents 9 Countries

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Quick Support

Product Information

Specification

Cm	0.24 mm/N
Rated power	300 W
Maximum power	450 W
Nominal impedance Z	8 Ohm
Frequency response	fu–4200 Hz
Mean sound pressure level	92 dB (2.83 V/1 m)
Maximum linear displacement	+/−3.5 mm
Excursion limit	+/-8 mm
Resonance frequency fs	52 Hz
Height of front pole-plate	8 mm
Voice coil diameter	65 mm
Height of winding	15 mm
Cutout diameter	230 mm
D.C. resistance Rdc	6.5 Ohm
Mechanical Q factor Qms	9.59
Electrical Q factor Qes	0.34
Total Q factor Qts	0.33
Equivalent volume Vas	44 l
Effective piston area Sd	353 cm²
Dynamically moved mass Mms	37.6 g
Force factor Bxl	15.6 Tm
Inductance of the voice coil L	0.9 mH
Connections	Spring terminals
Part Number	3050
