Product Information
Specification
Application:
• These cables are used for the distribution of power in circuits rated for 600/1000 volts or may be used in lighting, communication, and control. • Typical applications include: A/C motor power; distribution pane feeders; transformer feeders; lighting panels; light fixtures; plugs/receptacles and remote controls.
Also Known As:
Offshore drilling cable, Marine power distribution cable 600/1kV, Marine cable, Unarmored power cable, Drilling rig cable, Multi-C LS armored cable , Marine and rig power cable.
Standards:
• IEC 60092-350 • General construction and test methods of power, control and instrumentation cables for shipboard and offshore applications. • IEC 60092-351 • Insulating materials for shipboard and offshore units, power, control, instrumentation, telecommunication and data cables. • IEC 60092-353 • Power cables for rated voltages 1 kV and 3 kV. • IEC 60092-359 • Sheathing materials for shipboard power and telecommunication cables. • IEC 60092-352 • Electrical installations in ships - Part 352: Choice and installation of electrical cables. • IEEE 45 - 2002 • Recommended Practice for Electrical Installations on Shipboard Cable, as noted in Clause 23.3 for products manufactured per IEC 60092-350 series.
Approvals:
• Intertek, as Type HF XLPE / SHF1. • ABS, American Bureau of Shipping. • LRS, Lloyd’s Register of Shipping. • DNV, Det Norske Veritas
Features:
• Enginnered for easiest installation. • Maximum conductor operating temperature: • 90 °C as per IEC. Drilmar HF XLPE Insulation: • Low Smoke and Halogen Free XLPE meeting IEC 60092-351. • Rated at 90 °C. • SHF1 Jacket: • Low Smoke and Halogen Free Polyolefin metting IEC 60092-359. • Completed cable offers superior flame resistance meeting: • IEC 60332-1 and IEC 60332-3-22 Category A. • Low Smake as per IEC 61034-2. • Halogen Free as per IEC 60754-1.
